Gilson 306 HPLC Pump Isocratic/Binary System 10-200 mL/min USA Used
Gilson
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension15.0in x 12.0in x 6.0in
-
Serial361G5D034
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 60Hz US
Description
The Gilson 306 HPLC Pump, manufactured by Gilson, is renowned for its reliability and efficiency in chromatography systems. As part of a multi-pump setup, this Model 306 serves primarily as a slave pump, controlled by either a computer with Gilson software or a Gilson 305 Master pump. Designed for both analytical and preparative HPLC, it supports isocratic, binary, and tertiary configurations, offering a wide range of flow rates from 10 L/min to 200 mL/min. The pump ensures precise chromatographic separation, suitable for various liquid viscosities due to interchangeable pump heads. This used equipment, originating from the United States, is functional and offers a cost-effective solution for enhancing laboratory results. Note: Computer is not included.
Key Features
- Wide flow rate range: 10 L/min to 200 mL/min
- Supports isocratic, binary, and tertiary configurations
- Designed for multi-pump applications
- Controlled by computer or Gilson 305 Master pump
- Interchangeable pump heads for varied liquid viscosities
Specifications
- Front Panel Control: No
- Flow Rate Range: 10 L/min - 200 mL/min
- Power Voltage: 110-120 / 220-240 V~
- Purification Technique: HPLC
- Hydraulic System: Reciprocating pump with single-piston interchangeable head
- Operating Pressure: 0.160 MPa (1-600 bar, 14.5-8700 psi)
- Pump Type: Isocratic, binary, and tertiary configurations
Weight
Imperial: 12.0 Pounds
Metric: 5.44 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 14.4 lb x 7.2 lb
Metric: 45.72 cm x 36.58 cm x 18.29 cm
Harmonized Code
902780
Harmonized Code Details
902780 - Instruments For Physical Or Chemical Analysis, Or For Measuring Or Checking Viscosity (e.g., Rheometers) - This code applies as the Gilson 306 fits the criteria for instruments utilized in precise chemical analysis processes, specifically chromatography equipment.
