Gilson 306 HPLC Pump 120V 60Hz US 30-Day Warranty, 100% Parts and Labor

Product Information

Welcome to the world of the Gilson 306 HPLC Pump! Combine it with manometric modules and dynamic mixers. This pump is cost-effective and highly dependable - ideal for analytical to preparative HPLC. The interchangeable pump heads accommodate flow rates ranging from 10 L/min to 200 mL/min, handling a variety of liquids at differing viscosities. Whether it's isocratic, binary, or tertiary configurations, the Gilson 306 Pump is designed to excel. Now for the quirkier facts - this Model 306 is tailored for multi-pump applications. It acts as a slave pump in Gilson chromatography systems, intelligently controlled either by a computer with Gilson software or by a Gilson 305 Master pump acting as a system controller. The flow rates delivered range widely between 10 L/min to 200 mL/min, whether isocratic or gradient HPLC applications. This reliable chromatographic workhorse is easily controlled through TRILUTION LC software or using a standalone keypad, depending on the model. Accessories such as manometric modules and dynamic mixers further enhance the pumping action. For easy and problem-free mobile phase mixing, this unit comes equipped to minimize pressure fluctuations and pulse dampener for smooth flows.

• Interchangeable pump heads for a variety of flow rates
• Can be used in isocratic or gradient HPLC applications
• Easily controlled through TRILUTION LC software or standalone keypad
• Accessories such as manometric modules and dynamic mixers for enhanced pumping action

• Front Panel Control: No
• Flow Rate Range: 10 L/min - 200 mL/min
• Power Voltage: 110-120 / 220-240 V~
• Purification Technique: HPLC
• Hydraulic System: Reciprocating pump with single-piston interchangeable head
• Operating Pressure: 0.160 MPa (1-600 bar, 14.5-8700 psi) depending on pump head used
• Pump Type: Isocratic, binary, and tertiary configurations

Metric: 5.9 kg
Imperial: 13 lbs

Metric: 38.1 cm x 30.48 cm x 15.24 cm
Imperial: 15 in x 12 in x 6 in

8413810010

The harmonized code 8413810010 refers to the category 'Pumps for liquids, whether or not fitted with a measuring device; liquid elevators'. This is the most appropriate description for the Gilson 306 HPLC Pump due to its function and application in the laboratory and industry settings.
