Gilson 306 HPLC Pump Used Functional Analytical to Preparative Flow Rates
Gilson
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension15.0in x 12.0in x 6.0in
-
Serial361M6D080
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 60Hz US
Description
The Gilson 306 HPLC Pump offers a cost-effective, reliable solution for both analytical and preparative high-performance liquid chromatography (HPLC) applications. This used model is in good condition, showing signs of cosmetic wear but fully functional, supporting a wide range of liquid viscosities with interchangeable pump heads. Featuring a flow rate capacity from 10 L/min to 200 mL/min, it functions as a slave pump within Gilson chromatography systems and can be controlled by a Gilson 305 Master pump or appropriate software. It's ideal for multi-pump settings, using isocratic, binary, or tertiary configurations for precise chromatographic separations. The system operates on a voltage of 120V and 60Hz frequency, with a single-piston reciprocating hydraulic system capable of handling operating pressures up to 8700 psi, depending on the pump head used.
Key Features
- Flow Rate: 10 L/min to 200 mL/min
- Interchangeable pump heads for various viscosities
- Isocratic, binary, and tertiary configurations
- Controlled via Gilson 305 or software
- Operating pressure up to 8700 psi
- 120V, 60Hz power supply
Specifications
- Model: 306
- Voltage: 120V
- Frequency: 60Hz
- Flow Rate Range: 10 L/min - 200 mL/min
- Hydraulic System: Single-piston reciprocating
- Operating Pressure: 14.5-8700 psi depending on pump head used
- Control: No front panel, controlled via 305 master or software
Weight
Imperial: 12.0 Pounds
Metric: 5.44 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 14.4 lb x 7.2 lb
Metric: 45.72 cm x 36.58 cm x 18.29 cm
Harmonized Code
902780
Harmonized Code Details
902780 - Instruments and apparatus for physical or chemical analysis. This fits because the Gilson 306 is used for analytical chromatography processes.
