Nikon Eclipse TS2 Inverted Routine Microscope

Product Information

The Nikon Eclipse TS2 Inverted Routine Microscope is a compact and simple design with powerful functionality. It utilizes Nikon's CFI60 optical system and LED illumination for both Diascopic and Epi-fluorescence imaging, providing clear images and efficient cell culture observation. The LED light source offers faster setup and consistent results, enhancing workflow efficiency. With streamlined operation, easy-to-use mechanical stage, and a compact, stable body, it is a versatile and durable tool. The microscope has an array of observation methods, optical systems, and high performance features, making it ideal for various applications in life science research and routine laboratory work. This second-hand unit is in near new condition with 30-day warranty, offering excellent value and functionality.  Typical applications include cell observation, documentation, and fluorescence observation in culture rooms.

Technician comment

Objectives: 20x/0.40 Ph1 ADL 10x/0.25 Ph1 ADL 4x/0.10

Key Features

1. CFI60 Infinity Optical System
2. LED illumination for Diascopic and Epi-fluorescence imaging
3. Streamlined operation with intuitive control buttons
4. High performance mechanical stage for various sample types
5. Compact, stable, and vibration-resistant body
6. Comes with a 30-day parts and labor warranty

Specifications

1. Optical System: CFI60 Infinity Optical System
2. Observation method: Brightfield, Apodized Phase Contrast, Phase Contrast, Emboss Contrast
3. Diascopic illumination: High luminescent white LED illuminator (Eco-illumination), Built-in Fly eye lens
4. Tube: Inclination - 45 degrees, Pupillary distance - 50-75 mm, Siedentopf type, Attachable camera port, Eyepiece/Port:100/0:0/100
5. Focusing: Via nosepiece up/down movement, Stroke (manual): Up 7 mm down 1.5 mm
6. Condenser: ELWD Condenser (NA 0.3, W.D. 75 mm)
7. Slider: Precentered or Centering PH Slider, 10X, 20X, 40X objectives available for Phase Contrast, Emboss Contrast sliders
8. Stage: Plain Stage, stage size - 170 (X) x 247 (Y) mm, Mechanical stage (optional), stroke: 126 (X) x78 (Y) mm
9. Dimensions: 236 (W) x 548 (D) x 471 (H) mm
10. Weight (approx.): 13 kg
11. Rated Voltage/Electric Current: 100V-240VAC±10%, 50/60Hz, 0.35A

Weight

Metric: 13 kg

Imperial: 28.66 lb

Dimensions

Metric: 236 cm x 548 cm x 471 cm

Imperial: 92.91 in x 215.75 in x 185.43 in

Harmonized Code

901180

Harmonized Code Details

Microscopes for photomicrography, cinephotomicrography or microprojection
