Glen Dimplex JHI-1500-M Chiller/Heater Air-Cooled 1.5 Ton 230V Portable
Glen Dimplex/Koolant Koolers
Details
-
CategoryChiller / Heater
-
Dimension36.0in x 26.0in x 34.0in
-
SerialW299030-001
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz230V / 60Hz US
Description
The Glen Dimplex/Koolant Koolers JHI-1500-M is a robust air-cooled chiller providing precision temperature control for a variety of process fluids within a 50-80°F range, operating efficiently in ambient temperatures of 50-95°F. Mounted on casters, it offers seamless portability and versatility, making it ideal for numerous laboratory and industrial applications such as spot welders, waterjets, and small lasers. Featuring a 1.5-ton chiller capacity and a 10-gallon reservoir, this unit supports water or water/glycol operations with temperature stability of ±3°F. Its compact design ensures compatibility with existing setups without the need for special wiring, exemplifying plug-and-play simplicity. Crafted in the United States and housed in a stainless steel cabinet, the JHI-1500-M integrates advanced components like a hermetic compressor, brazed plate evaporator, and a Carel IR33 digital controller. This model, currently in good condition, powers on and performs basic tests without known functionality issues, despite not being fully tested.
Key Features
- 1.5-ton chiller capacity
- BTUs/Hr: 18,000
- Temperature control: 50-80°F
- Reservoir Capacity: 10 Gallons
- Portable and easy to service
- Water or water/glycol operation
Specifications
- Manufacturer: Glen Dimplex/Koolant Koolers
- Model: JHI-1500-M
- Sub-Model: 801057
- Condition: Good
- Reliable temperature control from 50-80°F
- Ambient temperature range: 50-95°F
- Fluid temperature stability: ±3°F
- 10-gallon reservoir
- Chiller capacity: 1.5 ton
- BTU’s/Hr: 18,000
- Volts/Phase: 230/1 or 460/3
- Hz: 60
- Refrigerant: R134a
- Dimensions: Length 30.625 in, Width 25.125 in, Height 35.25 in
- Wet weight: 570 lbs
Weight
Imperial: 684.0 Pounds
Metric: 310.26 Kilograms
Shipping Dimensions
Imperial: 43.2 lb x 31.2 lb x 40.8 lb
Metric: 109.73 cm x 79.25 cm x 103.63 cm
Harmonized Code
841869
Harmonized Code Details
The harmonized code 841869 covers industrial chillers as it comprises refrigerating or freezing equipment. This code is used for equipment in similar categories, justifying its assignment here.
