Termaline 8141 Coaxial Resistor Oil-Cooled Bench Load 250W -40C to +45C
Termaline Coaxial Resistor
Details
-
CategoryMiscellaneous
-
Dimension12.0in x 6.0in x 9.0in
-
Serial9993
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Termaline Coaxial Resistor Model 8141 is a robust, portable, and self-contained 50-ohm coaxial transmission line termination, ideal for RF testing in medium-power base stations. The unit operates effectively without external power, thanks to its oil-cooled, convection cooling system capable of handling continuous operations up to 250W in environments from -40C to +45C. Quick Change connectors facilitate seamless critical measurements up to 2.5 GHz. Its design, including a low-profile housing, handle, and rubber feet, ensures stable and reliable usage in demanding settings. Although unable to undergo full testing, the unit powers on, appears functional, and retains no significant known issues.
Key Features
- 250W continuous power rating
- Oil-cooled convection system
- Frequency Range: DC to 2.5 GHz
- Operating Temperature: -40C to +45C
- Low-profile housing with handle
- N(F) Quick Change connectors
Specifications
- Power Rating: 250W continuous
- Frequency Range: DC to 1 GHz (VSWR 1.1 max), 1 GHz to 1.8 GHz (VSWR 1.2 max), 1.8 to 2.5 GHz (VSWR 1.3 max)
- Temperature Range: -40 to +45C
- Coolant: 0.35 gal. (1.3 liters) Silicone Oil
- Operating Position: Horizontal Only
- Connectors: N (F)
- Finish: Gray Powder Coat
Weight
Imperial: 13.2 Pounds
Metric: 5.99 Kilograms
Shipping Dimensions
Imperial: 14.4 lb x 7.2 lb x 10.8 lb
Metric: 36.58 cm x 18.29 cm x 27.43 cm
Harmonized Code
853340
Harmonized Code Details
Harmonized code 853340 applies to electrical resistors, designed for use in electronic circuits. The Termaline 8141 fits in this category due to its function as a coaxial resistor component used primarily for testing RF transmission settings.
