Masterflex 77201-60 Pump Head Peristaltic L/S Four Roller 2300ml/min New
MasterFlex
Details
-
CategoryPump
-
Dimension5.0in x 4.0in x 5.0in
-
Serial1022010114
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Masterflex 77201-60 Easy-Load II Pump Head features a robust and compact design, perfect for precision fluid handling in laboratory and industrial settings. Its versatile four-roller rotor enhances pressure performance and mechanical stability while reducing pulsation. This pump head supports various L/S Precision tubing sizes, allowing quick tubing changes without removing the head from the drive, thanks to its automatic tubing retention system. For applications requiring high flexibility, the adjustable occlusion allows for modification based on pressure requirements. This model accepts six L/S tubing sizes and offers a maximum flow rate of 2300 ml/min, optimal for multichannel applications with stackable configurations. The Masterflex 77201-60 is designed for durability with housing made from Polyphenylene sulfide (PPS) and a stainless steel rotor, maintaining consistent performance across a range of operational speeds from 0.02 - 600 rpm. This unit supports effortless maintenance and space-saving installation with a smooth operational procedure that meets stringent laboratory environments.
Key Features
- Four-roller rotor for enhanced pressure performance
- Automatic tubing retention with quick change capability
- 2300 ml/min max flow rate
- Adjustable occlusion for various pressure needs
- Compatible with six L/S tubing sizes
- Housing made from durable PPS material
- Stainless steel rotor for mechanical stability
- Stackable for multichannel applications
Specifications
- Model: 77201-60
- Rollers: 4
- Max. Flow Rate: 2300 ml/min
- Housing Material: Polyphenylene Sulfide (PPS)
- Rotor Material: Stainless Steel
- Dimensions (H x L x W): 121 mm x 82 mm x 127 mm
- Gear Ratio: 1:1
- Number of Channels: 1
- Occlusion: Adjustable
- Open-head Sensor: No
- Optimal RPM Range: 0.02 - 600 rpm
- Pump Series: L/S
- Suction Lift: 8.8 m (29 ft.)
- Tubing Retention: Automatic
- Tubing Sizes Accepted: L/S 13, L/S 14, L/S 16, L/S 17, L/S 18, L/S 25
Weight
Imperial: 6.0 Pounds
Metric: 2.72 Kilograms
Shipping Dimensions
Imperial: 6.0 lb x 4.8 lb x 6.0 lb
Metric: 15.24 cm x 12.19 cm x 15.24 cm
Harmonized Code
841319
Harmonized Code Details
The harmonized code 841319 covers pumps for liquids, whether or not fitted with a measuring device; other than reciprocating or rotary positive displacement pumps. This code is apt for the Masterflex 77201-60 Pump Head, being a specialized peristaltic pump used for precision fluid handling.
