Thermo VF-P20-A Quaternary Pump Flow Rate 8mL/min Pressures Up to 103 MPa
Thermo Fisher Scientific
Details
-
CategoryPump
-
Dimension42.0cm x 62.0cm x 34.0cm
-
Serial8314281
-
Shipping TypeFedEx Ground
-
Manufacturing2019-10-21
-
Voltage / Hertz230V / 50Hz/60Hz
Description
The Thermo Quaternary Pump F, model VF-P20-A (2019), offers enhanced solvent blending capabilities as part of the Vanquish LC platform. Utilizing SmartFlow technology, it ensures precise flow and gradient control even at high backpressures up to 1034 bar, enhancing data precision and reliability during complex gradient runs. Originally manufactured in Germany, this used pump is untested but powers on, with no known functionality issues, making it ideal for complex chromatographic applications. The pump features a built-in solvent degassing system across four channels, temperature range from 5°C to 35°C, and a maximum flow rate of 8 mL/min. With dimensions of 42 cm in width, 62 cm in depth, and a height of 19.2 cm, the pump fits efficiently into laboratory settings for method development and application switching.
Key Features
- SmartFlow technology for precision
- High backpressure up to 1034 bar
- Quaternary solvent blending
- Maximum flow rate of 8 mL/min
- Built-in 4-channel solvent degassing
- Temperature range of 5°C to 35°C
- Biocompatible with pH range 2 to 12
Specifications
- Model: VF-P20-A
- Type: Quaternary Serial Dual-Piston Pump
- Flow Accuracy: 0.1%
- Flow Precision: <0.05% RSD or <0.01 min SD
- Gradient Formation: Low-Pressure Gradient Proportioning
- Max Flow Rate: 8 mL/min
- Pressure Range: 2 to 103 MPa
- pH Range: 2 to 12
- Chloride Concentration: Up to 1 mol/L
- Solvent Degassing: Built-in, 4 channels
- Temperature Range: 5°C to 35°C
- Power Supply: 230V, 50/60Hz
Weight
Imperial: 47.62 Pounds
Metric: 21.6 Kilograms
Shipping Dimensions
Imperial: 19.84 lb x 29.29 lb x 16.06 lb
Metric: 50.39 cm x 74.4 cm x 40.79 cm
Harmonized Code
8413.50
Harmonized Code Details
8413.50 - Pumps for liquids, whether or not fitted with a measuring device; liquid elevators. This code is appropriate as it fits the description of scientific liquid pumps, reflecting the equipment's purpose and specifications.
