Thermo Scientific Vanquish Diode Array Detector HL VH-D10-A

Product Information

***Sold without UV lamp***

Thermo Scientific Vanquish Diode Array Detector HL VH-D10-A is a high-performance, reliable, and flexible HPLC and UHPLC detection equipment. It offers excellent linearity and noise performance, with an ultra-wide dynamic range to detect concentrated compounds and trace-level impurities. The LightPipe technology provides the best signal-to-noise performance through low baseline noise, a long light path, and minimal dispersion. This detector is used in pharmaceutical analysis, food and beverage testing, and environmental analysis for its high sensitivity and ultra-fast data collection rate. With a single-beam diode array, it achieves drift of less than 0.5 mAU/hour at 230nm which is suitable for UV-vis detection with up to 10 channels. The standard, LightPipe flow cell allows high sensitivity detection while the diagnostic cell includes GLP features for system monitoring. With a weight of 17 kg, and dimensions of 160 mm x 420 mm x 620 mm, it is suitable for use in various lab settings.

Key Features

1. Ultra-wide dynamic range for detecting concentrated compounds and trace-level impurities
2. LightPipe technology for best signal-to-noise performance and minimal dispersion
3. GLP features for predictive performance monitoring and system parameter logging
4. UV-vis detection mode with up to 10 channels
5. Diode array with drift of less than 0.5 mAU/hour at 230nm

Specifications

1. Data Collection Rate: Up to 200 Hz
2. Detector Type: Single-Beam Diode Array
3. Flow Cell Volume: Standard, LightPipe flow cell, 10mm; High Sensitivity, Light Pipe flow cell, 60mm; LightPipe diagnostic cell
4. Lamp: Deuterium lamp
5. Linearity: < 5% at 2.0 AU (typically < 5% at 2.5 AU)
6. Max. Cell Operating Pressure: Limit 6 MPa (60 bar, 870 psi)
7. No. of Channels: 10 + 3D field
8. PC Connection: USB 2.0
9. Photodiode Array: 1024 element
10. Spectral Bandwidth: Pixel resolution: 0.5nm (average); Optical resolution: 1nm (FWHM with 1nm slit width)
11. Temperature Range: 5 to 35°C
12. Wavelength Accuracy: 1 nm
13. Wavelength Repeatability: 0.1 nm
14. Electrical Requirements: 100240 V AC, 50/60 Hz, max. 150 W/255 VA
15. Dimensions: 160 mm x 420 mm x 620 mm
16. Weight: 17 kg

Weight

Metric: 17 kg

Imperial: 37.48 lb

Dimensions

Metric: 160 cm x 420 cm x 620 cm

Imperial: 63 in x 165.35 in x 244.09 in

Harmonized Code

9027300000

Harmonized Code Details

The harmonized code 9027300000 is for spectrometers using optical radiations (UV, visible, IR) and its parts such as spectrophotometers. This code applies to instruments that can measure or detect in real time multiple wavelengths in a sample such as this diode array detector.
