Meritech CleanTech 500EZ Handwashing Station Automated 12-sec Cycle Stainless
Meritech
Details
-
CategoryProduction / Manufacturing
-
Dimension22.0in x 31.0in x 24.0in
-
SerialDoes Not Apply
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Meritech CleanTech 500EZ Automated Handwashing Station, manufactured in the United States, is a highly durable system designed specifically for industrial production environments. This model features a stainless steel, watertight cabinet that is designed for wall mounting in high-use areas. It offers a 12-second wash and rinse cycle that activates automatically via infrared photo-optical sensors, ensuring consistent hand hygiene. The station also includes a visible compliance monitor to track hand wash cycles. Constructed with 304 stainless steel and equipped with NEMA 4X electronics, the system is CIP friendly and offers an LED light bar for solution level indication. An optional integrated air curtain dryer is available. This handwashing station is clinically proven to remove more than 99.9% of harmful pathogens when used with Meritech's UltraPure Hand Hygiene Solution, featuring water consumption of 0.6 gallons per cycle. With dimensions of 46 cm width x 50 cm depth x 70 cm height, it is ideally fitted for various industrial settings needing stringent hygiene compliance.
Key Features
- Automated 12-second wash and rinse cycle
- Infrared photo-optical sensors
- Stainless steel construction
- Wall-mounted design
- Visible compliance monitor
- NEMA 4X electronics enclosure
- Optional integrated air curtain dryer
- Effective hand washing beyond wrists to forearms
Specifications
- Hand Washing Cycle: 12 seconds
- Water Consumption: 0.6 gallons (2.3 L) per cycle
- Electrical: 100-240 VAC 50/60 Hz, 160 W
- Plumbing Requirements: 3/4" male hose, hot and cold with minimum 4 GPM flow
- Pressure: 40-100 PSI (2.8 - 6.9 Bar), optimal at 50 PSI
- Drain: Standard 1 1/2" (40 mm) drain stub
- Compressed Air: Recommended supply line of 3/8" inside diameter
- Solutions Storage: 1 - 2.5 gallon (10L) container of UltraPure Hand Hygiene Solution
- Weight: 76 lbs. (34.5 kg)
Weight
Imperial: 91.2 Pounds
Metric: 41.37 Kilograms
Shipping Dimensions
Imperial: 26.4 lb x 37.2 lb x 28.8 lb
Metric: 67.06 cm x 94.49 cm x 73.15 cm
Harmonized Code
842490
Harmonized Code Details
Code 842490 is used for parts and machinery for liquid or powder treatment, which fits the description of an automated handwashing station.
