PerSeptive Biosystems CytoFluor Series 4000 Fluorescence/Bioluminescence Reader
PerSeptive Biosystems
Details
-
CategoryAnalytical
-
Dimension19.0in x 15.0in x 9.0in
-
SerialFX6PMT543P
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The PerSeptive Biosystems CytoFluor Series 4000 is a high-performance fluorescence/bioluminescence reader designed to accurately measure soluble and cell-associated fluorescence. This used instrument is in very good condition, with minor cosmetic wear, and remains fully functional and tested to support successful operation. It features precise temperature control from 5°C to 45°C in 0.2°C increments and incorporates a low noise, high gain photomultiplier tube placed in a lightproof detection chamber. The CytoFluor Series 4000 covers an excitation wavelength range of 320-700 nm and emission wavelength 390-800 nm. It manages solution and cell-based assays, accommodating standard microplates of 6, 48, 96, and 384 wells. The system's versatile optics can configure to read the top or bottom of the plate, featuring a quick 60-second scan speed. The unit operates at 120V/220V and supports frequencies of 50Hz/60Hz.
Key Features
- Fluorescence and Bioluminescence Reading
- Temperature Control: 5°C to 45°C in 0.2°C increments
- Photo Multiplier Tube Detection
- EM Wavelength Range: 390 - 800 nm
- EX Wavelength Range: 320 - 700 nm
- Supports 6, 48, 96, and 384 well microplates
- 60-second scan speed
- Reconfigurable top/bottom optics measurement
Specifications
- Detection Mode: Fluorescence Intensity
- Detector: Electron Tubes, Inc. 9781 Photomultiplier Tube (Low Noise, High Gain)
- Filters: 6-cavity design interference filters for CytoFluor
- Lighting: Tungsten-halogen, 50 watt, nominal 3,000 hours life
- Voltage: 120V/220V, Hertz: 50Hz/60Hz
- Dimensions (cm): 19.0 L x 15.0 W x 9.0 H
- Weight: 18 kg
Weight
Imperial: 48.0 Pounds
Metric: 21.77 Kilograms
Shipping Dimensions
Imperial: 22.8 lb x 18.0 lb x 10.8 lb
Metric: 57.91 cm x 45.72 cm x 27.43 cm
Harmonized Code
902750
Harmonized Code Details
Harmonized code 902750 is designated for instruments and apparatus for physical or chemical analysis, particularly using fluorescence and photometric methods. This category fits the CytoFluor Series 4000 as it primarily engages in fluorescence intensity measurement.
