Cavro MSP 9500 Automated Sample Processor Liquid Handling Station
Cavro
Details
-
CategoryLiquid Handling
-
Dimension24.0in x 32.0in x 20.0in
-
Serial730215
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Cavro MSP 9500 is a compact, fully automated sample processor ideal for various liquid handling operations in laboratory settings. Known for its modular construction, this device allows for easy customization tailored to specific sample handling applications. The MSP 9500's robust and dependable design is perfect for placement in laboratory fume and laminar flow hoods, featuring a 15" x 31" work area. This unit, although used, is in very good condition and fully functional. It showcases a travel range on the X, Y, and Z axes allowing for precision operations with resolutions as fine as 0.2234mm on the X-axis. The sample processor is designed to handle a versatile volume range from 2 L to 25 mL. This equipment operates on both 120V and 220V power and is compatible with frequencies of 50Hz and 60Hz.
Key Features
- Compact and fully automated
- Customizable modular design
- Fits in lab fume and laminar flow hoods
- Rugged and dependable
- 15" x 31" work area
- Handles volumes from 2 L to 25 mL
- High precision travel range
Specifications
- Travel Range: X-Axis 563mm/22.17", Y-Axis 300mm/11.81", Z-Axis 165mm/6.57"
- Travel Range (Steps): X-Axis 2533 steps, Y-Axis 2109 steps, Z-Axis 1700 steps (3400 with 2:1 gear ratio)
- Resolution per Half Step: X-Axis 0.2234mm, Y-Axis 0.1422 mm, Z-Axis 0.0982mm
- Initialization Offset: X = 5 Steps, Y = 5 Steps, Z = 20 Steps
- Power Requirements: 120V/220V, 50Hz/60Hz
- No Computer included
- Includes Power Cord
Weight
Imperial: 120.0 Pounds
Metric: 54.43 Kilograms
Shipping Dimensions
Imperial: 28.8 lb x 38.4 lb x 24.0 lb
Metric: 73.15 cm x 97.54 cm x 60.96 cm
Harmonized Code
847989
Harmonized Code Details
The harmonized code 847989 covers machines and mechanical appliances not specified or included elsewhere, which fits the description for automated sample processors used in laboratory settings.
