Bioer MB-101 ThermoCell Mixing Block Used 300-1500 RPM RT-14C to 100C
Bioer
Details
-
CategorySmall Benchtop Equipment
-
Dimension13.0in x 9.0in x 8.0in
-
SerialBYQ6008U-173
-
Shipping TypeFedEx Ground
-
Manufacturing2009-01-01
-
Voltage / Hertz120V / 50Hz/60Hz
Description
The Bioer MB-101 ThermoCell Mixing Block from 2009 expertly combines mixing functions with precise temperature control, essential for incubating and reacting samples. Utilizing advanced Peltier Effect heat exchange technology, this unit ensures consistent and accurate temperature management, accommodating plates and tubes with its selection of interchangeable blocks. Key features include precise time, temperature, and speed control, a PID Circuit for exact temperature regulation, and a robust direct current motor for reliable mixing with minimal noise even at high speeds up to 1500 rpm. The device offers a temperature setting range from 0 to 105 C and control from RT-14 C to 100 C with remarkable accuracy and uniformity within 0.5 C. Its large VFD display and easy-to-use interface enhance user-friendliness. Note, a computer is not included in the package.
Key Features
- Comprehensive mixing and temperature control
- Peltier Effect heat exchange technology
- Interchangeable blocks for plates and tubes
- PID Circuit for precise temperature control
- Direct current motor for reliable mixing
- Large VFD display for user-friendly interface
- Mixing speed range: 300 to 1500 rpm
- Temperature setting range: 0 to 105 C
Specifications
- Temp. Setting Range: 0 - 105 C
- Temp. Control Range: RT -14 C ~ 100 C
- Timing Range: 1 min ~ 99 h 59 min
- Mixing Speed: 300 rpm ~ 1500 rpm
- Mixing Amplitude: 3 mm
- Temp. Control Accuracy: less 0.5 C
- Display Accuracy: less 0.5 C
- Temp. Uniformity: less 0.5 C
- Heating Time: < 12 min (20 C to 100 C)
- Cooling Time: < 8 min (RT to RT -10 C), < 15 min (100 C to RT + 10 C)
Weight
Imperial: 21.6 Pounds
Metric: 9.8 Kilograms
Shipping Dimensions
Imperial: 15.6 lb x 10.8 lb x 9.6 lb
Metric: 39.62 cm x 27.43 cm x 24.38 cm
Harmonized Code
8419899890
Harmonized Code Details
Tariff code 8419899890 describes machinery for temperature control methods. This code is suitable for products like the Bioer MB-101 due to its specialized function of both heating and cooling samples in a lab setting.
