Agilent 5183-4644 Gas Pressure Regulator 2-Stage Stainless & Brass
Agilent
Details
-
CategoryMiscellaneous
-
Dimension9.0in x 7.0in x 5.0in
-
SerialN/A
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Agilent 5183-4644 Multi Stage Regulator is designed to precisely reduce the pressure of gases such as helium, argon, and nitrogen from high-pressure cylinders, making it ideal for operating various laboratory equipment and instruments. With a maximum output of 125 psi, this 2-stage regulator includes a CGA580 connection and a 1/8 inch fitting, suitable for 1/4 inch tubing with an adapter. Built with durable 316 stainless steel diaphragms, a brass body and bonnets, and PTFE seats, it is engineered for reliable performance. Despite cosmetic wear and an inability to fully test, it powers on and appears to function normally, with no known issues impacting its operability. This used and functional regulator does not include additional accessories such as power cords or manuals.
Key Features
- 2-stage pressure regulation
- Handles helium, argon, nitrogen gases
- 125 psi max output
- CGA580 connection
- 1/8 inch fitting for 1/4 inch tubing
- 316 stainless diaphragms
- Brass body and bonnets
- PTFE seats
Specifications
- 2-stage regulator with 125 psi max output
- Compatible gases: helium, argon, nitrogen
- Fitting: 1/8 inch, adapter needed for 1/4 inch tubing
- CGA580 connection
- Materials: 316 stainless steel diaphragms, brass body and bonnets, PTFE seats
Weight
Imperial: 7.2 Pounds
Metric: 3.27 Kilograms
Shipping Dimensions
Imperial: 10.8 lb x 8.4 lb x 6.0 lb
Metric: 27.43 cm x 21.34 cm x 15.24 cm
Harmonized Code
84811000
Harmonized Code Details
84811000: Pressure-reducing valves. The code is chosen based on the product being a multi-stage pressure regulator used in gas supply systems.
