Agilent G1330B Chiller Heater Peltier Control Air Temp Range -40C to 70C 50Hz
Agilent
Details
-
CategoryChiller / Heater
-
Dimension18.0in x 14.0in x 6.0in
-
SerialDEBAK11293
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Agilent 1290 Infinity G1330B Thermostat, part of the Agilent 1200 Infinity Series, is an essential component for liquid chromatography (LC) systems. It uses advanced Peltier-controlled heat exchangers for highly efficient air-based temperature regulation, suitable for a variety of laboratory settings. The unit features a fan that circulates air through cooling/heating modules, ensuring even temperature control over the sample vial tray of the autosampler. This design effectively manages temperature adjustments, with condensation safely disposed of through an integrated leak system. With settings ranging from -40°C to 70°C, the thermostat is adaptable to a range of environmental conditions while maintaining optimal performance across altitudes up to 2000 meters. Compliant with IEC, CSA, and UL safety standards, this unit is suitable for indoor laboratory use. Manufactured in Germany and weighing approximately 43 pounds, this used unit powers on, performs basic tests, implying functionality despite untested status.
Technician comment
This unit has been tested for basic power function. See photos for details.
Key Features
- Peltier-controlled heat exchangers
- Temperature range: -40°C to 70°C
- Efficient air-based temperature control
- Compatible with Agilent 1200 Infinity Series
- Powerful air circulation with integrated fan
- 100–240V voltage input
Specifications
- Temperature range: -40°C to 70°C
- Power consumption: 260 VA / 210 W / 717 BTU
- Voltage: 120V/220V
- Hertz: 50Hz/60Hz
- Ambient operating temperature: 4°C to 40°C
- Humidity: <95% r.h. at 40°C non-condensing
- Operating altitude: Up to 2000 m (6562 ft)
- Safety Standards: IEC, CSA, UL Installation category II
Weight
Imperial: 51.6 Pounds
Metric: 23.41 Kilograms
Shipping Dimensions
Imperial: 21.6 lb x 16.8 lb x 7.2 lb
Metric: 54.86 cm x 42.67 cm x 18.29 cm
Harmonized Code
902789
Harmonized Code Details
902789 - Instruments and apparatus for physical or chemical analysis, or for measuring or checking viscosity, porosity, expansion, surface tension or the like. This code is used for devices like the Agilent G1330B due to its analytical capabilities in laboratory settings.
