Vaisala DMT 340 Dewpoint & Temperature Transmitter - Digital Display
Vaisala
Details
-
CategoryMeter
-
Dimension8.0in x 3.0in x 10.0in
-
SerialT4350949
-
Shipping TypeFedEx Ground
-
Manufacturing2021-01-01
-
Voltage / Hertz100-240V / 50Hz/60Hz
Description
The Vaisala DMT 340 Dewpoint & Temperature Transmitter, manufactured in 2021, is a robust device engineered for demanding industrial applications like compressed air drying and metal treatment. This used transmitter, in good condition, features the DRYCAP sensor, capable of delivering reliable measurements in dew points down to -60°C. Equipped with a menu-based LCD display and data logging capability, the unit automatically stores a year's worth of data. It also includes a unique auto-calibration function to maintain measurement accuracy. With a working voltage of 100-240V, the device powers on without issues and includes a power cord for immediate installation. Note the unit has minor cosmetic marks from prior usage. For details on location-specific applications and features, consult the accompanying technical specifications.
Technician comment
Preowned item, powers on without issues. Has slight scratches all around from regular use. Power cord ready to be install. See photos for further details.
Key Features
- Reliable dewpoint measurement down to -60°C
- DRYCAP sensor technology
- LCD display with menu interface
- Data logging for one year
- Automatic calibration adjustments
- Power input: 100-240V
- Functions despite minor cosmetic wear
Specifications
- Min RH Range: 0%
- Max RH Range: 70%
- RH Accuracy: 0.004% RH 20% of reading
- Min Temperature: 32°F (0°C)
- Max Temperature: 176°F (80°C)
- Temperature Accuracy: 0.2°C
- Dew Point Range: -76°F to 176°F (-60°C to 80°C)
- Response Time: 30 seconds
- Output: 4-20mA
- Height: 10 cm (4 inches)
- Width: 7.5 cm (3 inches)
- Depth: 8 cm (3.15 inches)
Weight
Imperial: 4.8 Pounds
Metric: 2.18 Kilograms
Shipping Dimensions
Imperial: 9.6 lb x 3.6 lb x 12.0 lb
Metric: 24.38 cm x 9.14 cm x 30.48 cm
Harmonized Code
902580
Harmonized Code Details
Harmonized Code 902580 covers measuring apparatus for temperature or humidity and includes devices like the Vaisala DMT 340, suitable for its comprehensive dewpoint and temperature applications in industrial settings.
