Vaisala DMT 340 Dew Point Temperature Transmitter - Remote Probe, -60°C
Vaisala
Details
-
CategoryMeter
-
Dimension8.0in x 3.0in x 10.0in
-
SerialT4350948
-
Shipping TypeFedEx Ground
-
Manufacturing2021-01-01
-
Voltage / Hertz100-240V / 50Hz/60Hz
Description
The Vaisala DMT340 Dew Point and Temperature Transmitter, manufactured in 2021, is designed for industrial applications involving dry conditions such as compressed air drying and metal treatment. This device ensures precise and consistent measurements, even in dew points down to -60°C. Featuring the resilient DRYCAP sensor, it's resistant to contamination from particulates, condensation, oil vapor, and many chemicals. Its auto-calibration function allows it to maintain accuracy by automatically adjusting the calibration curve if needed. Though it couldn't be tested fully, the unit powers on and performs satisfactorily during basic tests with no known functionality issues. The device includes a power cord and exhibits minor cosmetic wear.
Technician comment
Preowned item, powers on without issues. Has slight scratches all around from regular use. Power cord ready to be install. See photos for further details.
Key Features
- Robust DRYCAP sensor immune to contaminants
- Auto-calibration for precision
- Suitable for industrial dry applications
- Displays and logs one year of temperature and dew point data
- Reliable operation in temperatures from 0°C to 80°C
Specifications
- Min RH Range: 0%
- Max RH Range: 70%
- Min Temperature: 0°C (32°F)
- Max Temperature: 80°C (176°F)
- Temperature Accuracy: 0.2°C
- Min Dew Point Range: -60°C (-76°F)
- Max Dew Point Range: 80°C (176°F)
- RH Accuracy: 0.004% RH
- Response Time: 30 seconds
- Display: LCD
- Output: 4-20mA
- Power Input: 10 to 35 VDC
Weight
Imperial: 4.8 Pounds
Metric: 2.18 Kilograms
Shipping Dimensions
Imperial: 9.6 lb x 3.6 lb x 12.0 lb
Metric: 24.38 cm x 9.14 cm x 30.48 cm
Harmonized Code
902510
Harmonized Code Details
902510 - Thermometers and pyrometers, not combined with other instruments, non-electric. Used this code as the product functions in temperature measurement.
