Acme TP1A Transformer Large 480V 30 KVA Industrial Application 60Hz
Acme Electric
Details
-
CategoryFacility
-
Dimension20.0in x 25.0in x 26.0in
-
SerialDoes Not Apply
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz480V / 60Hz US
Description
The Acme Electric Model TP1A Large General Purpose Transformer, categorized under catalog number TP533123S, is a robust unit specifically engineered for industrial and commercial use. Engineered to support three-phase courses at 60Hz, this transformer efficiently operates with a primary voltage of 480 Delta and a secondary calculation of 208Y/120 volts. The model is adept for environments characterized by harsh chemical exposure or high salt mist, making it suitable for waste water treatment facilities, coastal areas, and similar applications. Despite cosmetic blemishes and minor issues potentially affecting its function, this unit represents high value when fully operational. Mounting the transformer requires hardwiring, housed in a UL Type 3R/Type 2 enclosure, emphasized by an encapsulated design for weather resistance. Featuring an expansive wiring compartment, it is UL Listed and CSA certified, offering an insulation system UL Class 220C, a 150C rise, ensuring cooler case temperatures and secure adaptability.
Technician comment
Transformer will need to be hard wired. Stains around unit.
Key Features
- Rated for three-phase at 60Hz
- 480 Delta to 208Y/120 volts conversion
- 30 KVA power capacity
- Enclosed in UL Type 3R/Type 2 housing
- Suitable for corrosive environments
Specifications
- 480V Delta primary and 208Y/120 secondary voltages
- Supports a 4-wire 480Y/277 volt supply
- Weather-resistant UL Type 3R/Type 2 enclosure
- UL Class 220C insulation with 150C rise for cooler operation
- Extra large wiring compartment for easy installation
Weight
Imperial: 402.0 Pounds
Metric: 182.34 Kilograms
Shipping Dimensions
Imperial: 24.0 lb x 30.0 lb x 31.2 lb
Metric: 60.96 cm x 76.2 cm x 79.25 cm
Harmonized Code
8504.33
Harmonized Code Details
8504.33: Transformers having a power handling capacity exceeding 16 KVA but not exceeding 500 KVA; based on input primary & secondary voltage capability, suited for its industrial application.
