Leonard TM-600-LF Drench Shower Valve 90F Max Temp, 58GPM, Thermostatic Mixing
Leonard
Details
-
CategoryHood
-
Dimension14.0in x 17.0in x 10.0in
-
SerialEMV659109LF
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
Introducing the Leonard LF Single Drench Shower Valve TM-600-LF, designed for precise temperature control in industrial and laboratory settings. Featuring the advanced ECO-MIX DURA-trol® solid bimetal thermostat, this valve adeptly manages hot and cold water intake, addressing supply temperature and pressure fluctuations. With a locking type regulator preventing accidental temperature changes, the valve is preset at 85°F with a recommended hot inlet temperature of 140°F. A notable safety feature is the valve's ability to close on cold water failure and a special internal cold water bypass that delivers up to 20 GPM at 30 PSI if the hot water supply fails. Robust with full 3/4-inch top or bottom inlets and a 1-inch top outlet, it's ideal for use in environments requiring steady temperature maintenance. Certified for low lead content, it ensures safety and compliance with environmental standards.
Key Features
- ECO-MIX DURA-trol® solid bimetal thermostat
- Thermostatic mixing with temperature locking
- Cold water bypass up to 20 GPM at 30 PSI
- Max flow rate: 58 GPM
- Adjustable high temp limit set at 90°F
- Integral wall support
Specifications
- Cold Water Bypass: 20 GPM
- Inlets: 3/4 inch
- Maximum Flow (GPM): 58 GPM
- Minimum Flow (GPM): 3 GPM
- Outlet: 1 inch
- Overall Depth: 9 inches
- Overall Width: 15 inches
- Dial Thermometer Range: 0 to 140°F (-10 to 60°C)
- Finish: Rough bronze
Weight
Imperial: 21.6 Pounds
Metric: 9.8 Kilograms
Shipping Dimensions
Imperial: 16.8 lb x 20.4 lb x 12.0 lb
Metric: 42.67 cm x 51.82 cm x 30.48 cm
Harmonized Code
8481.80.1095
Harmonized Code Details
8481.80.1095 - Other appliance, valve or faucet parts: These devices typically manage the flow and mixture of liquids, particularly in industrial settings, like thermostatic mixing valves.
