Leybold D4B CPD Storage Vacuum Pump with Low Noise and High Speed
leybold
Details
-
CategoryPump
-
Dimension28.0in x 14.0in x 13.0in
-
Serial200307232
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Leybold Trivac D4B Vacuum Pump is reliable and designed for long service life, with a focus on durability. Despite some cosmetic defects and missing power cable, this used unit offers significant value due to its high functionality. It features a built-in oil pump for force-feed lubrication, minimizing wear and surface corrosion with non-ferrous metal components. The unit operates quietly with low vibration and modern vacuum technology, achieving high pumping speeds and low ultimate pressures with sustainable water vapor tolerance. Adaptable for continuous operation up to 1000 mbar, the pump is equipped with horizontal or vertical intake and exhaust ports, a pressure-controlled anti-suckback valve, and multiple O-rings made of elastomer FPM. Though previously used, the Leybold D4B maintains its utility in scientific and industrial applications, being environmentally friendly and compact with an air-cooled system and retractable handle for easy maneuvering. Computer is not included.
Key Features
- High pumping speed with ultimate pressure
- Force-feed lubrication ensuring trouble-free operation
- Equipped with a gas ballast valve
- Non-ferrous metal construction for corrosion resistance
- Environmentally friendly with low noise operation
Specifications
- Nominal pumping speed: 4.8-5.8 m3/h (2.8-3.4 cfm)
- Ultimate partial pressure without gas ballast: 10^-4 mbar (0.75 x 10^-4 Torr)
- Ultimate total pressure with gas ballast: < 5 x 10^-3 mbar (< 3.8 x 10^-3 Torr)
- Water vapor tolerance: 30 mbar (22.5 Torr)
- Oil filling: 0.3 to 0.8 liters
- Noise level: 50-52 dB(A) with/without gas ballast
- Motor rating: 370 W (0.50 HP)
- Admissible ambient temperature: 12-40°C (54-104°F)
- Voltage: 120V/220V, Hertz: 50Hz/60Hz
- DN16 KF Intake and Exhaust Connections
Weight
Imperial: 76.8 Pounds
Metric: 34.84 Kilograms
Shipping Dimensions
Imperial: 33.6 lb x 16.8 lb x 15.6 lb
Metric: 85.34 cm x 42.67 cm x 39.62 cm
Harmonized Code
84141000
Harmonized Code Details
84141000 - Vacuum pumps: Vacuum pumps are classified under this code due to their function of lowering air pressure within a chamber to create vacuum, suitable for Leybold D4B's purpose.
