Tracor LFG-1300S Signal Function Generator Used 0.02Hz-2MHz 120V 50/60Hz
Tracor
Details
-
CategoryMiscellaneous
-
Dimension12.0in x 10.0in x 6.0in
-
Serial6031176
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 50Hz/60Hz
Description
The Tracor LFG-1300S is a versatile function generator in very good condition, featuring a frequency range from 0.02Hz to 2MHz. This used unit, originating from the United States, is equipped to support various research, design, and service applications with its sine, square, triangle, ramp, and pulse output signals. Despite slight cosmetic blemishes and missing front buttons, it remains fully functional. The generator provides linear and logarithmic sweep frequency outputs with sweep widths up to 1000:1, and allows both frequency and amplitude modulation by an external signal. It operates on 120V at 50/60Hz and includes a power cord. This model is a reliable choice for laboratories seeking high-precision signal generation.
Key Features
- Frequency range: 0.02Hz to 2MHz
- Provides sine, square, triangle, ramp, and pulse outputs
- Variable pulse symmetry over a 9:1 range
- Linear and logarithmic sweep frequency outputs
- Calibrated 70 dB attenuator
- External signal modulation capability
- Operates at 120V 50/60Hz
Specifications
- Make: Tracor
- Model: LFG-1300S
- Frequency range: 0.02Hz to 2MHz
- Waveforms: Sine, Square, Triangle, Ramp, Pulse
- Sweep range: 0.002Hz to 2MHz in 8 ranges
- Accuracy: (0.02Hz to 200kHz) ±3% reading, ±3% full scale; (200kHz to 2MHz) ±5% reading, ±5% full scale
- Voltage: 120V, 50/60Hz
- Dimensions: 12in x 10in x 6in
Weight
Imperial: 10.8 Pounds
Metric: 4.9 Kilograms
Shipping Dimensions
Imperial: 14.4 lb x 12.0 lb x 7.2 lb
Metric: 36.58 cm x 30.48 cm x 18.29 cm
Harmonized Code
8543.20
Harmonized Code Details
8543.20 - Electrical machines and apparatus, as there is no standard code specifically for function generators. This category covers similar electrical signaling equipment.
