Brooks 5860S Mass Meter Air Gas 0-30in Min Standalone Measurement Device
Brooks
Details
-
CategoryMeter
-
Dimension6.0in x 4.0in x 2.0in
-
Serial0106070315905001
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Brooks 5860S Smart Mass Flow Meter is a reliable tool for accurately measuring gas flows. It uses a thermal mass flow sensor to produce an electrical output signal based on flow rate. Designed for standalone use, this model features microprocessor-based electronics and a control-valve module to achieve stable gas flows. With a flow range of 0-30 in/min and adjustable flow signals, this unit is ideal for laboratory settings intending to measure precise air/gas flows up to a maximum of 300 bar. The flow meter is in good condition, though it has some cosmetic damage from use, as depicted in the photos. This instrument ensures repeatability with a 0.25% rate and provides excellent stability and controllability for processes that demand precise gas management.
Key Features
- Smart Mass Flow Meter for accurate gas measurement
- Standalone instrument with microprocessor-based electronics
- Integrally-mounted control-valve module for stable flow
- Can handle max pressure up to 300 bar
- Flow signal adjustable via software: 0-5 Vdc/1-5 Vdc or 0-20 mA/4-20 mA
- Accuracy of 0.5% of rate and 0.1% F.S.
- Repeatability of 0.25% of rate
- Rangeability and controllability: 50:1 and 100:1
- Less than 0.5% of rate stability per year
Specifications
- Flow Ranges: 0.003 min f.s to 30 in/min max
- Adjustable Flow Signal: 0-5 Vdc, 1-5 Vdc, 0-20 mA, 4-20 mA
- Flow Accuracy: 0.5% of rate, 0.1% F.S.
- Repeatability: 0.25% of rate
- Rangeability: 50:1
- Controllability: 100:1
- Pressure Range: Up to 300 bar
- Stability: Less than 0.5% of rate per year
- Temperature Zero Stability: Less than 0.075% F.S. per degree C
- Product Condition: Used, Functional, Cosmetic Damage
Weight
Imperial: 2.4 Pounds
Metric: 1.09 Kilograms
Shipping Dimensions
Imperial: 7.2 lb x 4.8 lb x 2.4 lb
Metric: 18.29 cm x 12.19 cm x 6.1 cm
Harmonized Code
902620
Harmonized Code Details
Harmonized Code 902620: Instruments and apparatus for measuring or checking pressure (not elsewhere specified or included). Used this code as the Brooks 5860S is designed to accurately measure gas flows which inherently involves pressure monitoring.
