Alltech 800 ELSD Evaporative Light Scattering Detector, 1-110C Range, Used
Alltech
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension15.0in x 17.0in x 15.0in
-
Serial800-0301001
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V / 50Hz/60Hz
Description
The Alltech 800 Evaporative Light Scattering Detector offers reliable application of light scattering technology for detecting non-volatile solutes in chromatography eluent streams. This used unit from 800 ELSDE series, designed with precision, features a 670nm/5mW laser diode and a silicon photodiode detector element. Capable of operating in temperatures ranging from ambient to 110°C, it efficiently handles solvent evaporation with impact technology that removes large droplets at low temperatures. The Alltech 800 boasts a nebulizer gas flow up to 3.0L/min, with gas inlet pressures of 15-90 psi (1.0-6.0 Bar). Despite minor cosmetic scratches and a Gas and Laser Alarm, the unit remains functional and a great addition for optimizing particle size detection in scientific and industrial applications. Note: Computer is not included.
Key Features
- Evaporative Light Scattering Detection
- 670nm/5mW Laser Diode
- Silicon Photodiode Detector Element
- Temperature Range: Ambient to 110°C
- Nebulizer Gas Flow: Up to 3.0 L/min
- Gas Inlet Pressure: 15-90 psi (1.0-6.0 Bar)
- Analog Outputs: 1V or 10mV full scale
- Efficient Solvent Evaporation
Specifications
- Light Source: 670nm/5mW laser diode
- Detector Element: Silicon photodiode
- Temperature Range: Ambient to 110°C
- Nebulizer Gas Flow: Max 3.0L/min
- Gas Inlet Pressure: 15-90psi (1.0-6.0 Bar)
- Mobile Phase Flow Rate: 1-5.0 mL/min
- Analog Outputs: 1V or 10mV full scale
- Scattering Efficiency: Lower at higher wavelengths, 30mW Laser
Weight
Imperial: 30.0 Pounds
Metric: 13.61 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 20.4 lb x 18.0 lb
Metric: 45.72 cm x 51.82 cm x 45.72 cm
Harmonized Code
902790
Harmonized Code Details
HS Code 902790 - Instrument for physical or chemical analysis, parts and accessories. This code is applicable as the Alltech 800 ELSD is used for chemical analysis involving light scattering detection.
