Cytiva AKTA Process Chromatography System GMP-Compliant Scalable Includes Software
Cytiva
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension40.0in x 70.0in x 65.0in
-
Serial29696934
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
This Cytiva AKTA Process Chromatography System, model 'ÄKTA Process', was designed for process scale-up and large-scale biopharmaceutical manufacturing. It is a highly flexible automation system with over 1 million possible configurations, suitable for use in GMP-regulated environments. Despite being considered brand new and unused, this unit has an internal short circuit issue which requires servicing. The main transformer emits a buzzing noise when powered, ceasing when one output wire is disconnected, indicating a shorted component. This versatile system can handle varying flow rate ranges from 1 L/h to 2000 L/h with configurable stainless steel or polypropylene piping. It includes a compatible computer with the required software, enhancing its efficiency. Ideal for GMP manufacturing, compatible with AxiChrom chromatography columns, and suitable for industrial-level documentation and accuracy. Industrial-standard components and automatic sensor calibration make it apt for biomanufacturing alignment and calibration tasks.
Technician comment
The unit was tested and does not power on. An internal short circuit is suspected. The main transformer produces a buzzing noise when powered. When one output wire is disconnected from the transformer, the buzzing stops. A shorted component in the system requires service. The unit is brand new and has never been used.
Key Features
- Over 1 million configuration options
- Handles flow rates from 1 L/h to 2000 L/h
- GMP-compliant automation system
- Compatible with AxiChrom columns
- Includes computer with software
- Suitable for process scale-up and GMP environments
- Industrial-standard components
- Automatic sensor calibration
Specifications
- Brand: Cytiva
- Model: AKTA Process Chromatography System
- Flow Rate Range: 1 L/h to 2000 L/h
- Piping Materials: Electropolished stainless steel or polypropylene
- Design: Flexible, configurable for diverse process demands
- Includes: Computer with software, power/data cables
- Suitable For: Large-scale biopharmaceutical manufacturing
- Validation: Designed for compliance with GMP regulatory standards
- Calibration: UV, pH, and conductivity sensors with traceability
Weight
Imperial: 2400.0 Pounds
Metric: 1088.62 Kilograms
Shipping Dimensions
Imperial: 48.0 lb x 84.0 lb x 78.0 lb
Metric: 121.92 cm x 213.36 cm x 198.12 cm
Harmonized Code
9027.8000
Harmonized Code Details
9027.8000 - Instruments and apparatus for physical or chemical analysis is suitable for apparatus used to conduct high-accuracy analysis. The AKTA process system falls under this category due to its implementation in biopharmaceutical chromatographic analysis.
