Hamilton Microlab Star Automated Liquid Handler 1000uL Pipetting iSWAP Gripper
Hamilton
Details
-
CategoryLiquid Handling
-
Dimension92.0in x 48.0in x 103.0in
-
SerialH579
-
Shipping TypeFreight
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Hamilton Microlab Star equipped with the STAR AL 16 arm and iSWAP gripper offers a versatile solution for high-throughput sample processing and liquid handling. Capable of precision pipetting up to 1000 µL per channel with advanced air displacement technology, this system ensures accuracy across genomics, proteomics, cell biology, and drug discovery labs. The modular deck supports carriers and accessories for seamless tube, reservoir, or plate operations. The iSWAP gripper automates labware transport, enhancing workflow efficiency and accuracy. Includes Microlab STAR AL 16 channel iSWAP gripper with custom bench and accessories such as TELESHAKE magnetic shaker and USB to serial adapter. Made in the USA by Hamilton, Serial Number H579, condition is new—unused with possible cosmetic scratches.
Technician comment
Includes: Microlab STAR AL 16 channel, iSWAP gripper with Custom bench & accessories. Included components: 173002-049 STAR 16 AL iSWAP gripper 173027 ASSY, DECK, STAR, WELDED CHASSIS – 1 EA - 173032 HOUSING ASSY, STAR – 1 EA - 190220 1 SWAP LANDSCAPE – 1 EA - 170320-C01 CHANNEL PAIR, 1000 UL PIPETTING – 8 EA - 173041 ADD-ON ARM, WELD CHASSIS – 1 EA - 911642V4 MODULAR ARM B, 4-12, 16, 96 PR, SW – 1 EA - 911642V4 SW TOOLS BASE PACKAGE V4.5 – 1 EA - Configuration 000178 – Sub-components - OTP-D50012236 LEUZE BC RASTER – 1 EA - 184089 CORE GRIP 1000 UL WASTE BLOCK – 1 EA - 185926 MPH WASTE CHUTE – 1 EA - 186469-R00 PLATE, MOUNTING, WASTE – 1 EA - 186895-R00 TIP CARRIERS, TIP RACKS – 5 EA - 187250-R00 PRECISION TAB PLT CAR, DWP – 5 EA - 187270-R00 PRECISION TAB PLT CAR, MTP – 1 EA - 187405 PLATEBASE, 74 T AP CPAC – 1 EA - 187462 TELESHAKE MAGNETIC SHAKER – 1 EA - 187463 VARIOMAG TELESHAKE – 1 EA - 187800-R00 TUBE WEIGHTS – 6 EA - 187800-R00 NEEDLE, TEACHING, SET OF 8 – 1 EA - 2032739 CUSTOM BENCH – 1 EA - 0201379-00 ADAPTER, USB TO SERIAL 4-PORT – 1 EA -
Key Features
- Precision pipetting up to 1000 µL per channel
- 16 independent pipetting channels
- iSWAP gripper for automated labware transport
- Modular deck for carrier and accessory integration
- Advanced liquid level detection
- Intuitive VENUS software for custom scripting
Specifications
- Includes Custom Bench
- Up to 16 independent pipetting channels
- Pipetting volume: 0-1000 µL per channel
- Voltage: 120V/220V, Hertz: 50Hz/60Hz
- Advanced air displacement technology
- iSWAP gripper: internal Swivel Arm Plate Handler
- Advanced liquid level detection: capacitive and pressure-based
- Dimensions: 92.0 in L x 48.0 in W x 103.0 in H
Weight
Imperial: 1560.0 Pounds
Metric: 707.6 Kilograms
Shipping Dimensions
Imperial: 110.4 lb x 57.6 lb x 123.6 lb
Metric: 280.42 cm x 146.3 cm x 313.94 cm
Harmonized Code
902750
Harmonized Code Details
HS Code 902750: Instruments and apparatus for measuring or checking quantities of heat or sound, such as laboratory pipettes. This code was chosen as the system provides precise liquid handling capabilities relevant for laboratory use.
