Thermo Finnigan Trace GC Ultra GC System High Volume Injection 450C Max Temp
Thermo Electron
Details
-
CategoryHPLC / FPLC / GC / CE
-
Dimension61.0cm x 62.0cm x 48.0cm
-
Serial20042794
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / HertzDoes Not Apply / Does Not Apply
Description
The Thermo Finnigan Trace GC Ultra is a sophisticated gas chromatography system designed in Italy, excelling in both performance and versatility. This system features a column oven capable of heating at up to 120 degrees C per minute, reaching a maximum temperature of 450 degrees C. It is equipped with a True Cold On-Column Injector, allowing large volume injections up to 250 mL, complemented by a split-splitless injector with a double-sweeping chamber to prevent contamination, capable of handling up to 50 mL. The system is fully integrated with a Dual Jet CO2 Cryogenic Modulator facilitating complex sample characterization. A high throughput AS 3000 Autosampler with a 105 sample tray is also included. Additionally, configurations allow up to three detectors to operate simultaneously, providing substantial analytical flexibility. LAN interfacing is available for streamlined data connectivity. Please note that power cords, user manuals, and software are not included.
Key Features
- 120 C/min oven heat rate
- Max oven temperature: 450C
- True Cold On-Column Injector up to 250 mL
- Split-Splitless injector with double-sweeping chamber
- Integrated Dual Jet CO2 Cryogenic Modulator
- LAN interfacing for connectivity
- High throughput AS 3000 Autosampler with 105 sample tray
- Universal base with up to three detectors
Specifications
- Column oven max temperature: 450C
- Injector temperature range: 5-400C
- High volume injection capability: up to 250 mL
- Split-Splitless injector operation with up to 50 mL
- Includes Dual Jet CO2 Cryogenic Modulator
- Network ready with Local Area Networking
- Autosampler capacity: 105 sample tray
Weight
Imperial: 119.05 Pounds
Metric: 54.0 Kilograms
Shipping Dimensions
Imperial: 28.82 lb x 29.29 lb x 22.68 lb
Metric: 73.2 cm x 74.4 cm x 57.61 cm
Harmonized Code
902720
Harmonized Code Details
902720: Gas Chromatographs. This code is suitable given the make and model is a gas chromatography system, designed for analyzing and separating gas phase compounds.
