Hewlett Packard 53131A Universal Frequency Counter 225 MHz Bench-Top
Hewlett Packard
Details
-
CategoryTesting Equipment
-
Dimension14.0in x 9.0in x 5.0in
-
Serial3416A04364
-
Shipping TypeFedEx Ground
Description
The Hewlett Packard 53131A Universal Frequency Counter is designed for precision and accuracy, making it ideal for laboratory and industrial applications. This used unit is in good working condition and has been verified to power on and pass basic functional tests. It features dual channels capable of measuring frequencies up to 225 MHz, with optional extensions up to 3.0 GHz, 5.0 GHz, or 12.4 GHz. The frequency resolution reaches 10 digits per second, and time interval resolution is 500 picoseconds. It supports extended temperature or frequency drift scenarios with optional high-stability oscillators. The standard HP-IB and RS-232C interfaces enable seamless data communication and automation. Its robust build is suited for bench-top and lower-volume ATE operations, providing ample functionality for measurement, automatic limit testing, and SCPI programming capability.
Key Features
- Measures frequencies up to 225 MHz
- Dual channels with optional extensions up to 12.4 GHz
- Resolution of 10 digits per second and 500 picoseconds
- Suitable for bench-top and ATE operations
- HP-IB and RS-232C interfaces
Specifications
- Frequency Measurement: Up to 225 MHz on Channels 1 & 2
- Optional Frequency Extensions: 3.0 GHz, 5.0 GHz, or 12.4 GHz
- Frequency Resolution: 10 digits per second
- Time Interval Resolution: 500 picoseconds
- External Reference Capability: 1, 5, 10 MHz
- Interfaces: HP-IB, RS-232C
- Applications: Bench-top measuring, ATE operations
Weight
Imperial: 24.0 Pounds
Metric: 10.89 Kilograms
Shipping Dimensions
Imperial: 16.8 lb x 10.8 lb x 6.0 lb
Metric: 42.67 cm x 27.43 cm x 15.24 cm
Harmonized Code
9030337000
Harmonized Code Details
Harmonized code 9030337000 covers 'Instruments for measuring or checking voltage, current, resistance or power, with a recording device.' This code applies due to the universal counter's functionalities in measuring frequencies and other electronic parameters.
