Agilent G4240A HPLC-Chip Cube Protein Analyzer 5-40C Used Functional
Agilent
Details
-
CategoryAnalytical
-
Dimension15.0in x 12.0in x 14.0in
-
SerialDE91600503
-
Shipping TypeFedEx Ground
-
ManufacturingDoes Not Apply
-
Voltage / Hertz120V/220V / 50Hz/60Hz
Description
The Agilent G4240A HPLC-Chip Cube Interface, part of the Agilent 1260 Infinity family, is a robust chip/mass spectrometry system designed for protein identification applications in proteomics research. Manufactured in the USA, this used unit powers on and passes basic tests, despite showing slight cosmetic wear typical of previous use. It integrates seamlessly via CAN bus with other Agilent 1260 Infinity modules and connects the HPLC-Chip to the pumps and well-plate sampler. The cornerstone of this technology is the HPLC-Chip's 3D polyimide film structure, enabling reduced user intervention and enhancing nanospray operations. Key specifications include power consumption of 80W, operational temperature range of 5°C to 40°C, and compatibility with both 120V/220V at 50Hz/60Hz. Operating altitudes up to 2000m expand its application versatility.
Key Features
- Chip/mass spectrometry system for protein identification
- Integrates with Agilent 1260 Infinity modules
- 3D HPLC-Chip technology with polyimide films
- Reduces user interaction with nanospray
- 80W power consumption
- Operational temperature range: 5°C to 40°C
- Voltage compatibility: 120V/220V, 50Hz/60Hz
Specifications
- Power consumption: 80 W active power
- Operating temperature: 5°C to 40°C (41°F to 104°F)
- Non-operating temperature: -40°C to 70°C (-4°F to 158°F)
- Humidity: < 80% at 40°C (104°F) non-condensing
- Operating altitude: up to 2000 m (6500 ft)
- Non-operating altitude: up to 4600 m (14950 ft)
- Weight: 14 kg (31 lbs)
- Dimensions: 38 cm x 30 cm x 35 cm (15 in x 12 in x 14 in)
Weight
Imperial: 37.2 Pounds
Metric: 16.87 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 14.4 lb x 16.8 lb
Metric: 45.72 cm x 36.58 cm x 42.67 cm
Harmonized Code
902730
Harmonized Code Details
902730 - Spectrometers including mass spectrometers; primarily used for determining properties of proteins and other biological samples. Classified under this code due to its primary function in mass spectrometry and protein analysis.
